application

The product is suitable for measuring the pressure of liquids, vapors, gases, and other media that do not corrode copper alloys and tin solder due to non crystallization and non solidification. Widely used in industries such as chemical, environmental protection, and machinery.

Technical Specifications

Nominal diameter: Ø 40mm, Ø 50mm

Accuracy level: 2.5 level, 4.0 level

Measurement range: -0.1~0~0.1... 40MPa

Or other equivalent pressure vacuum range

Environmental temperature: -40 ℃~70 ℃

When the ambient temperature deviates from 20 ℃ ± 5 ℃, the indication error of the instrument shall not exceed 0.04%/℃

Process connection: Ø 40 M10x1, 1/8 "NPT

50 M14x1.5, 1/4 "NPT pressure sensing element:<10MPa C-type tube

>10MPa spiral tube

Liquid receiving material: Copper alloy

Case Material: Carbon Steel Spray Coating (304SS optional)

Instrument glass: Organic glass (flat glass optional)

Protection level: IP54
