application

The product adopts a fully stainless steel structure and is used for measuring gas or liquid media with slight corrosiveness and places with strong corrosiveness in the surrounding environment. Mainly used in industries such as petroleum, chemical, metallurgy, power, food, medicine, environmental protection, and machinery.

Technical Specifications

Nominal diameter: Ø 40, Ø 43, Ø 50, Ø 53, Ø 60, medium 63 c98、Ф100

Ф150、 200 in the middle Ф250

Accuracy level: Ø 40~Ø 63 2.5 level

C98~Ø 250 Class 1.0, Class 1.6 Measurement Range: Ø 40~Ø 98-0.1~0~0.1... 60MPa Ø 100~Ø 250-0.1~0~0.06250MPa or other equivalent pressure vacuum range

Environmental temperature: -40 ℃~70 ℃

Medium temperature: -40 ℃~100 ℃

When the ambient temperature deviates from 20 ℃+5 ℃, the indication error of the instrument shall not exceed 0.04%/℃. Process connection: Ø 40~Ø 98 M14x1.5 (other optional)

100~200 M20x1.5 (other options available)

Pressure sensing element:<10MPa C-type tube

>10MPa spiral tube

Liquid receiving material: 316L (optional Monel)

Case material: 304SS (316L optional)

Instrument glass: Ø 40~Ø 98 polycarbonate (excluding Ø 60) Other flat glass (safety glass optional)

Protection level: IP54, IP65, IP66
