Full stainless steel (shock resistant) double needle double tube differential pressure gauge YCSH (N)

application

The product is suitable for measuring two identical or different pressures and can indicate the two measured pressures and the pressure difference separately. The instrument consists of two independent measurement systems and indicator devices. Can be used for monitoring and controlling pumps, filters, etc; It can also be used for liquid level measurement inside sealed tanks. Widely used in industries such as petroleum, chemical, metallurgy, power, food, medicine, environmental protection, and machinery.

Technical Specifications

Nominal diameter: 100mm in the middle

Accuracy level: 1.6 level

Measurement range: 0~16kPa... 10MPa

Environmental temperature: -40 ℃~70 ℃

Medium temperature: -40 ℃~100 ℃

When the ambient temperature deviates from 20 ℃ ± 5 ℃, the indication error of the instrument shall not exceed 0.04%/℃

Process connection: M20x1.5 (customizable according to user requirements)

Pressure sensing element: C-type tube

Liquid receiving material: 316L (optional Monel)

Case material: 304SS (316L optional)

Instrument pointer: aluminum alloy, black

Instrument dial: aluminum alloy, white background with black letters

Instrument glass: Flat glass (safety glass optional)

Protection level: IP54, IP65, IP66

option

Diaphragm chemical sealing instrument liquid filling (glycerin, silicone oil, fluorine oil, etc.)
